PCB Layer:
2 LThickness:
1.6mmPCB Size:
130*75mmMin Size:
0402Min Pitch:
0.1mmApplication:
Power Electronics
|
Item |
Speci. |
|
PCB SMT Min thickness |
T＜0.1mm |
|
PCB SMT Max thickness |
T＞4.5mm |
|
PCB SMT Min Length |
L≥3mm, |
|
PCB SMT Min Width |
W≥3mm |
|
PCB SMT Max Length |
L ＞ 1200mm |
|
PCB SMT Max Width |
W＞ 500mm |
|
Min panel size |
0.3mm*0.2mm |
|
Max panel size |
200mm*125mm＜SMD |
|
component thickness |
6.5mm＜T≤15mm |
|
Min pin space |
0.3mm≤Pitch＜0.4mm |
|
Min ball space |
0.3mm≤Pitch＜0.5mm |
|
PCB DIP Min thickness |
T＜0.8mm |
|
PCB DIP Max thickness |
T＞2mm |
|
PCB DIP Min Length |
L≥50mm |
|
PCB DIP Min Width |
W≥30mm |
|
PCB DIP Max Length |
L≥1200mm |
|
PCB DIP Max Width |
W≥500mm |
|
Inter package |
Vacuum/ Antistatic Bag |
|
Outer package |
Carton |
|
SMT capacity |
Four Million point/day |
1. PCB production time: sample: 3-4 days / production: within 7 days
2. Fast pcb delivery: 24 hours for 2L ; 48 hours for 4L ; 72 hours for 6L.
3. Component purchase: 2 days if all components is available in our domestic market.
4. PCB Assembly: samples: within 8 days / mass production: within 12 days
|
LAYER |
PROTOTYPE |
MASS PRODUCTION (above 20 m2) |
|
|
Quick Turn |
Standard Time |
||
|
MC PCB |
48 hours |
4-5 days |
10-12 days |
|
PFC 1 L |
48 hours |
5-6 days |
12-13 days |
|
1L |
24 hours |
3-4 days |
8-10 days |
|
2L |
24 hours |
3-4 days |
8-10 days |
|
4L |
48 hours |
5-6 days |
8-10 days |
|
6L |
72 hours |
6-7 days |
10-12 days |
|
8L |
72 hours |
7-8 days |
12-14 days |
|
10L |
96 hours |
9-10days |
16-18 days |
|
