PCB Layer:
2 LThickness:
1.6mmPCB Size:
165*123mmMin Size:
0402Min Pitch:
0.15mmApplication:
Consumer Electronics
|
Item |
Speci. |
|
PCB SMT Min thickness |
T＜0.1mm |
|
PCB SMT Max thickness |
T＞4.5mm |
|
PCB SMT Min Length |
L≥3mm, |
|
PCB SMT Min Width |
W≥3mm |
|
PCB SMT Max Length |
L ＞ 1200mm |
|
PCB SMT Max Width |
W＞ 500mm |
|
Min panel size |
0.3mm*0.2mm |
|
Max panel size |
200mm*125mm＜SMD |
|
component thickness |
6.5mm＜T≤15mm |
|
Min pin space |
0.3mm≤Pitch＜0.4mm |
|
Min ball space |
0.3mm≤Pitch＜0.5mm |
|
PCB DIP Min thickness |
T＜0.8mm |
|
PCB DIP Max thickness |
T＞2mm |
|
PCB DIP Min Length |
L≥50mm |
|
PCB DIP Min Width |
W≥30mm |
|
PCB DIP Max Length |
L≥1200mm |
|
PCB DIP Max Width |
W≥500mm |
|
Inter package |
Vacuum/ Antistatic Bag |
|
Outer package |
Carton |
|
SMT capacity |
Four Million point/day |
All boards are produced according to IPC-6012 standards and inspected according to IPC-A-600 in the latest version. Our products are widely applied in communications, industrial control, power electronics, medical equipment, security electronics, consumer electronics, LED, etc. More than 90 percent of them were exported to Europe, North America, South America.
1. PCB production time: sample: 3-4 days / production: within 7 days
2. Fast pcb delivery: 24 hours for 2L ; 48 hours for 4L ; 72 hours for 6L.
3. Component purchase: 2 days if all components is available in our domestic market.
4. PCB Assembly: samples: within 8 days / mass production: within 12 days
|
LAYER |
PROTOTYPE |
MASS PRODUCTION (above 20 m2) |
|
|
Quick Turn |
Standard Time |
||
|
MC PCB |
48 hours |
4-5 days |
10-12 days |
|
PFC 1 L |
48 hours |
5-6 days |
12-13 days |
|
1L |
24 hours |
3-4 days |
8-10 days |
|
2L |
24 hours |
3-4 days |
8-10 days |
|
4L |
48 hours |
5-6 days |
8-10 days |
|
6L |
72 hours |
6-7 days |
10-12 days |
|
8L |
72 hours |
7-8 days |
12-14 days |
|
10L |
96 hours |
9-10days |
16-18 days |
Continually improve our quality, efficiency, service to satisfy thecustomer's requirement.
Quality Specifications:
1. ISO-9001:2018 Quality System Standard
2. Quality Standard: IPC-610-D class 2,
3. Soldering Standard: J-STD-001 class 1,2,3
4. ESD Standard: ESD-MIL-STD-1686
5. Workshop management:5S
6. FAI-first article inspection
7. In process visual inspection
8. AOI inspection
9. Machine calibration and preventative maintenance
Product compliant: RoHS
RoHS prohibited substances list :
NO. Name The upper limit(ppm=mg/kg)
1 Pb 0.1%(1000ppm)
2 Hg
0.1%(1000ppm)
3 Cd 0.001%(100ppm)
4 Cr VI+ 0.1%(1000ppm)
5 PBB
0.1%(1000ppm)
6 PBDE 0.1%(1000ppm)
